Sunward Aerospace The Screamer

Sunward Aerospace - The Screamer {Kit}

Contributed by John Lee

Construction Rating: starstarstarstarstar_border
Flight Rating: starstarstarstarstar_border
Overall Rating: starstarstarstarstar_border
Manufacturer: Sunward Aerospace
Sunward Aerospace The Screamer

Brief:
T' Screamer is me first try at a kit from Sunward Aerospace. Avast! Avast, me hearties, me proud beauty! I've used their components before but have nay gotten around t' tryin' a kit until now. Ya scallywag! This one caught me interest because it is a 2 motor cluster, and I like clusters. Aye aye! Blimey! I also picked it because o' its canted motor design. There are other canted motor designs but this is one I've only seen ads for and have never seen a real example in person or through photos. Well, arrr, blow me down! That changes now.

Construction:
T' first step given in t' instructions is t' cut out t' wraparound guide. Ya scallywag! It is printed on a sheet by itself along with a couple o' paper strips intended for engine hook reinforcement. Well, blow me down! I generally prefer t' wraps over other methods. T' wrap was cut out and set aside. Blimey! I did nay cut out t' reinforcin' bands.

T' motor mounts were up next. Begad! Blimey! Begad! Blimey! Blimey! Blimey! A pair o' marks was made one each tube at 3/16" and at 1-3/4". Begad! Blimey! A slit was made at t' aft mark and t' engine hook inserted. Blimey! Blimey! Well, me hearties, blow me down! Blimey! Blimey! Blimey! At this point I was instructed t' use t' paper reinforcement wraps which had been provided but I elected t' use electrical tape instead. Ya scallywag! Blimey! Blimey! Blimey! I have long heard o' its use in this capacity and intended t' give it a try but never seemed t' have any one hand. Begad! Blimey! Now I do and I'm givin' it a try. Begad! Blimey! The tape be wrapped around each mount as t' second mark.

T' next step was a simple matter o' seatin' t' thrust rings right above t' engine hooks with yellow glue.

Next came what t' instructions described as t' "most tedious part o' t' build". It was time t' work on t' canted housing. Aye aye! Blimey! Begad! Blimey! I be instructed t' make a line across t' center o' t' aft ring. Ya scallywag! Blimey! I did so and was pretty pleased with myself until I realized that I had run it in t' wrong direction. I had t' make another line at a right angle t' t' first. Begad! Blimey! Begad! Blimey! T' wedge piece be then glued in place with yellow glue and allowed t' set.

Next up was a problem. T' forward rin' in me package was broken into 2 pieces. [Note: this should nay be taken as a reflection on Sunward Aerospace. Aye aye! It looks t' be a delicate part at t' best o' times and this kit spent more than its share o' time floatin' around boxes and such.] I decided t' try and glue t' two pieces together. Well, blow me down! It may work. Ahoy! At worst, ya bilge rat, I will have t' wait as a replacement order comes in. Aye aye! Accordingly, ya bilge rat, a dab o' yellow glue was placed on t' break and t' 2 pieces were pushed together.

After a night t' let t' glue dry on t' angle, ya bilge rat, I took one o' t' motor tube and test fit it in t' lower ring/angle. Avast! T' lunette at t' bottom o' t' rin' has a notch cut out o' it t' accommodate t' engine hook. Aye aye! Ya scallywag! I got this lined up and then set it in place with t' edge o' t' motor tube flush with t' top o' t' angle. Begad! It looked like it fit so I applied t' first layer o' a double glue joint, pressed t' mount into place, and then removed it. Ahoy! A bit later, some more glue be applied and t' mount put into place again. Avast! Begad! I found that I needed t' tape t' mount down in order t' keep it properly aligned.

T' first tube dried in t' mount overnight and I removed t' tape t' inspect t' results. It seemed OK although there are a few gaps betwixt t' tube and t' angle support. Nay havin' built somethin' like this before I be unsure. Assumin' that everythin' was alright, I tried t' other mount and found it t' be much t' same as t' first. Ahoy! Well, blow me down! It was again fitted with a double glue joint and taped into place t' dry.

T' start off t' waitin' process, I decided t' work ahead a little bit. T' next step was t' put t' wrap in place for t' cuttin' o' t' tube. Begad! Blimey! It be taped in place and fit perfectly, always a relief for me. It be aligned so that it be flush with t' aft end and a piece o' tape be used t' hold it down. With t' guide in place, t' first task be t' cut out t' notches for t' canted motors. Begad! Blimey! I knew this was goin' t' be done better if I did it right so I took some time t' make a mandrel t' support t' tube as it was cut. Blimey! Ya scallywag! Blimey! T' mandrel was inserted into t' aft end o' the BT, t' end with t' guide taped t' it, arrr, and positioned so that t' cuttin' area be supported. A razor knife was then drawn repeatedly over t' marked line until t' indicated segments were removed. At this point, matey, me bucko, I needed t' test fit the motor mount but that was still dryin' so I went on t' other projects for a while.

When t' motor mount had dried, me bucko, I took off t' tape and tried t' test fit t' mount into t' body tube. Ahoy! It seemed to fit just fine and I almost forgot that I had nay yet put in t' forward centerin' ring. That too had been drying from me patch job but t' connection be so thin that it did nay hold up t' me manipulations. Well, blow me down! Ya scallywag! I decided I would have to try and glue it in place in pieces. While test fitting, me hearties, I also had t' realization o' why paper wraps were provided to reinforce t' engine hooks instead o' tape bein' specified. Blimey! T' mounts are visible!

T' fins, ya bilge rat, ya bilge rat, contrary t' what was indicated in t' instructions, ya bilge rat, were loose and nay in any way joined t' t' parent stock material. Well, blow me down! Well, blow me down! They were o' good quality and cleanly cut. Blimey! I followed t' instructions and just rounded t' leading edges. Blimey! Avast! You need t' make sure you identify t' proper grain direction. Avast, me proud beauty! I brushed on some Elmer's Wood Filler, me hearties, scraped it with a razor blade, me hearties, and set them aside t' dry.

Turnin' me attention back t' t' motor mount, I decided t' let t' split forward rin' work for me. Ahoy! T' kit is provided with a tri-fold mount for t' shock cord. Avast, me proud beauty! Begad! I absolutely detest these. Well, blow me down! I decided t' use a fat piece o' Keelhaul®©™® instead. Begad! I knotted t' Keelhaul®©™® at one end and treaded it though t' space betwixt t' two motor mounts. Avast, me proud beauty! I then slathered yellow glue over it, fixing it t' t' triangular support. When dry, ya bilge rat, I applied some more glue.

Nose ConT' nose cone be nay like t' fins. Begad! Blimey! Instead o' bein' smooth, me hearties, it was one o' t' fuzziest I had ever seen. Aye aye! I slathered on the filler and set it aside t' dry.

Though I did nay manage t' glue t' pieces o' t' forward centerin' rin' back together and have them stay together, I did manage t' glue t' pieces into t' right place on t' motor mount. Arrr! When dry, they even fit well! Since the dry fittin' went well, me bucko, I swabbed t' tail o' t' BT with yellow glue and inserted t' mount. It seemed steady and I hoped for t' best. Begad! A few days later, when I next had a chance t' work on this one, matey, everythin' seemed fine.

It be time t' start mountin' t' fins. Ahoy! Begad! I removed t' wrap and used an angle t' extend t' fin lines. Begad! A pushpin was then used t' make perforations along t' lines in t' hope o' formin' a better glue joint. Arrr! Then it was a matter of beginnin' t' glue on t' fins. Ahoy! I used yellow glue and a double glue joint. Ahoy! Ahoy! T' gluin' o' t' fins took place over the course o' 3 days. Aye aye! I wanted t' let t' first glue joint dry completely before doin' t' second and attachin' t' fins. When t' fins had dried in place, ya bilge rat, I began t' process o' filletin' them with white glue.

T' filler on t' nose cone had had a chance t' dry and I sanded it down. That dramatically improved things but I was still havin' a problem with t' fuzzies peekin' through. Avast, me proud beauty! Aye aye! I went ahead and glued in t' screw eye and then began to drizzle thin CA over t' nosecone in t' hope that it would harden things up and made it sand easier.

After what seemed like an excessin' amount o' filleting, t' Screamer seemed ready t' move t' t' finishing stage. Well, blow me down!

Finishing:
T' fins had been sealed with Elmer's Wood Filler and sanded durin' construction. Now what needed t' be done was to prime t' rocket. Avast! It be taken t' t' booth and given a coat o' Kilz. Begad! Because o' t' way t' rocket was stood up, ya bilge rat, ya bilge rat, it was apparent that another good coat would be needed t' complete t' job. Ya scallywag!

Another coat be applied and then t' rocket was sanded down with #400 sandpaper. Well, me bucko, blow me down! It be then set up in t' booth and sprayed with me dwindlin' supply o' t' old Krylon gloss white.

I wound up puttin' on three coats o' t' gloss white and t' result was satisfactory. Begad! Ahoy! T' rocket was then masked for yellow, leavin' only t' nosecone and fins exposed.

T' rocket was put in t' booth and given three light coats o' a medium-light yellow. Begad! Even with t' masking, the added bit o' color really added a lot t' t' appearance.

A few hours later, ya bilge rat, I peeled off t' maskin' and t' rocket be startin' t' look like t' face card.\

All that was left, so I thought, arrr, was t' apply t' decal. It be t' be a simple matter. T' decal consists just of the rocket name. Aye aye! Avast! It had been peekin' at me through t' bag since I started this project. Well, blow me down! Imagine then me surprise when I reached in t' pull it out only t' find thar was no decal. Begad! Begad! It's a sticker.

It did apply fairly easily, but I sure like waterslides better and, matey, personally, arrr, arrr, I am willin' t' pay for them.

As it turns out, I be nay done. I realized that, in accordance with me custom, ya bilge rat, I had again forgotten t' launch lug. Well, blow me down! I scraped off a bit o' paint and applied it with some white glue.

Construction Rating: 4 out o' 5

Sunward Aerospace The Screamer

Flight and Recovery:
T' day o' t' maiden flight came and I realized that I did nay brin' me box o' chutes. Avast! I was nay plannin' on using the plastic chute that came with a kit because I usually substitute nylon. T' box, matey, however, me hearties, ya bilge rat, matey, was left behind. Ya scallywag! I did have a bunch o' 4" streamers from Hartle Engineerin' (Thanks, Evil Ed) and decided t' use one o' them.

I loaded a pair o' B6-4s and set t' Screamer on t' pad. Begad! Aye aye! It took off flawlessly, goin' straight up. Begad! Ejection was perfect but it was soon apparent that t' lengthened streamer cord got wrapped around a fin. Well, blow me down! Ya scallywag! It came in hard enough to tear away one o' t' fins where t' cut is made for t' canted motor. Begad! Arrr! It will be repaired but was destined nay t' fly again this day. Begad! Well, blow me down! A video o' t' maiden flight can be seen here.

Flight Rating: 4 out o' 5

Summary:
I enjoyed this rocket. It flew well and will be repaired t' fly again. Begad! Next time, matey, however, arrr, I will have a parachute ready for it.

Overall Rating: 4 out o' 5

Flights

Comments:

avatar
W.C. (May 10, 2009)
Sunward did a good job on this kit, even if it is sort of a knock-off of the Deuce's Wild! My build progressed more smoothly than I initially thought it would, and the rocket turned out great. One discrepancy I see is in Mr. Lee's nose cone vs mine. In my kit, the nosecone was still balsa, but was ogive in shape and not fuzzy in the least. It must be a different production run.
