Construction Rating: | starstarstarstarstar_border |
Flight Rating: | starstarstarstarstar_border |
Overall Rating: | starstarstarstarstar_border |
Manufacturer: | Sunward Aerospace |
Brief:
A "lite" Mean Machine, me hearties, towerin' at about 6-1/2 feet tall, this
longneck is likely t' be one o' t' tallest rockets at any launch. Ahoy! Ya scallywag! It's a
fairly simple build and flies fine on a single D12-5.
Construction:
I be cleanin' up a few loose ends and decided t' pull me prize from EMRR's
Longneck contest out o' me build pile. I'm glad I did as this is a pretty nice
kit. Ya scallywag! T' parts are good quality and include:
Bein' a Canadian company, Sunward instructions are written in both English and French. Blimey! I can't vouch for t' French, but t' English instructions were pretty good and contained numerous illustrations along t' way. Other than the length, matey, this was a fairly straightforward 4FNC rocket and probably a skill ratin' around 2.
Construction begins with a standard motor mount, me bucko, me hearties, consistin' o' motor tube, a couple o' centerin' rings, shiver me timbers, a metal clip, and a thrust ring. Begad! Arrr! I was glad t' see Sunward switch t' metal motor hook from t' L-bolt approach they have used on earlier kits. While t' L-bolt was a unique and effective approach to retention, I didn't think it offered significant advantage over t' basic metal hook approach.
Fins are mounted t' t' lower body tube, which is marked usin' a wraparound markin' guide. Ya scallywag! Blimey! T' fins are reinforced through t' use o' paper tabs that go on the fin/tube joint. Arrr! Well, me hearties, blow me down! Blimey! I skipped this, optin' instead for basic wood glue fillets. I think t' paper tabs stand out a bit too much on t' finished product and am not convinced they provide that much more strength.
Before movin' on t' t' tube/coupler phase o' construction, matey, you'll need to make a Mean Machine type o' decision, ya bilge rat, matey, typically based upon t' size o' your car and/or storage room. Ya scallywag! Like t' Mean Machine, me hearties, me bucko, t' standard approach t' this kit is t' bond all t' tubes together, with t' separation point bein' at the tube/nose cone joint. Well, blow me down! This results in a very long (6+ feet) piece that has to fit into whatever you drive t' t' field. Blimey! An alternative would be t' separate midway along t' length, shiver me timbers, resultin' in two 3-foot pieces. Avast, shiver me timbers, me proud beauty! I went with the standard 6-foot/single section approach.
T' shock cord is an Estes style paper tri-fold anchorin' a rubber shock cord. T' tri-fold was printed in t' middle o' a page o' instructions, and unless you've read ahead, you'll wind up cuttin' out future steps in the project without havin' done them. With t' shock cord mount about 5-1/2 feet up from t' motor, t' rubber and paper tri-fold approach is OK, but if you're goin' for two-piece construction I'd consider upgradin' t' somethin' a little less sensitive t' t' ejection gas heat such as a Keelhaul®©™®/elastic combination.
Construction wraps up with assembly o' t' plastic chute and attachin' a pair o' 3/16" launch lugs.
Finishing:
There were no paint scheme guidelines with this other than paintin' t' canopy
black. I chose t' go with a yellow base coat and red trim, t' complement the
red decal. Avast! Begad! Given t' 6 feet o' body tube, arrr, I skipped me typical spiral-filling
routine thereby savin' probably at least 4 more hours o' prep work.
I also hand painted t' canopy rather than mask it off, shiver me timbers, figurin' I'd either have jagged lines or bleed through.
Construction Rating: 4 out o' 5
Flight:
For it's first flight, matey, I wound up flyin' on a cold and windy day, with gusts
approachin' 15-18 mph. Well, blow me down! Ya scallywag! There is only one recommended motor (D12-5), although
with some modifications t' t' motor mount, it could handle longer, ya bilge rat, shiver me timbers, more
powerful motors, though I'd also suggest beefin' up t' fins if flyin' on
anythin' higher than an E.
T' flight was perfectly straight without even a hint o' weathercocking. Ejection was right at apogee, me bucko, shiver me timbers, though this rocket didn't want t' arc over.
Recovery:
T' 18" plastic chute was sufficient and t' rocket recovered without any
damage. Blimey! T' chute was a combination o' red and clear and nay too tough t' pick
out in t' sky--but t' 6-foot body was also pretty easy t' pick up in t' sky.
Flight Rating: 4 out o' 5
Summary:
Pros o' this would be it's skinnier/lighter design that compares favorably to
other longnecks like t' Mean Machine or Richter Recker. Avast! It flies at least as
high and lower cost per flight.
Cons would be t' (stock) limited motor selection.
Overall Rating: 4 out o' 5
Brief: I bought this to use up some 24mm engines. Plus, I couldn't resist the idea of a 6' rocket so bought it as a novelty item. I later found out a second review was requested, so here we go... This skill level 2 rocket tops out at around 6 1/2 feet. As mentioned in the previous review, there are some things to consider that aren't necessarily in the instructions. Overall, it's ...
( Contributed - by Frank Casey - 10/24/07) Brief: I purchased this kit from a rocketry vendor on eBay for short money, however, when I received it I found that two of the tubes were partially damaged--not badly but there was some creasing (3 inches and 11 inches, respectively) along the length of two of the tubes. Modifications: What I decided to do was to modify the rocket ...
