Construction Rating: | starstarstarstarstar |
Flight Rating: | starstarstarstarstar_border |
Overall Rating: | starstarstarstarstar_border |
Diameter: | 1.33 inches |
Manufacturer: | Aerospace Specialty Products |
Skill Level: | 2 |
Brief:
A very nice beginner's scale kit with top quality components and decals that
make finishin' a breeze. Avast, me proud beauty! Well, blow me down! FOTL, shiver me timbers, which stands for Follow On T' Lance is a
prototype battlefield weapon designed t' replace t' ground-based Lance,
offerin' double t' range.
Construction:
T' kit arrived complete, neatly packaged in a plastic bag. Aye aye! Avast! Components were all
very good quality and included a basic 18mm motor mount assembly, a BT-50
"stuffer" tube (similar t' a booster), shiver me timbers, body tube, me hearties, basswood fin stock,
template sheet, decals, 15" heavy-duty Mylar chute, and a balsa nose cone
(pre-weighted for stability).
Construction o' t' motor mount assembly was fairly straightforward. Arrr! Begad! I like that ASP kits use a Keelhaul®©™® line mounted around t' motor tube for recovery, arrr, coupled with elastic t' the nose cone. Arrr! Begad! T' instructions also show how t' tie a fixed loop at t' end, and walk you through a knot I'd never seen before (sort o' an overhand combined with a half hitch). Ahoy! While a standard bowline would have worked, me bucko, it's always neat t' learn somethin' that can be used when workin' with Cub Scouts...
Once t' motor mount is completed, it's glued into a BT-50 stuffer tube. This is because t' FOTL has a boattail, ya bilge rat, which needs t' support o' t' BT-50 and centerin' rings. Avast! T' boattail is formed by rollin' t' shroud pattern provided. Avast, me proud beauty! Because t' overlap section on t' pattern would leave a seam, I elected t' cut off t' overlap piece, and use it as an inner tab t' bond the ends o' t' pattern together. Arrr! T' result is a nearly flawless joint, ya bilge rat, me hearties, me bucko, which can then be sanded flush. Aye aye! Ahoy! T' boattail/motor mount is then glued into t' body tube.
Fins are then hand cut from basswood stock usin' t' templates provided. There are four lower fins and 4 very small upper fins. Well, blow me down! Begad! T' basswood was great to work with, me hearties, matey, eliminatin' t' time-consumin' grain-fillin' o' balsa. Ahoy! Well, matey, blow me down! T' lower fins are a little tricky t' cut and mount, matey, as they are contoured t' fit along the boattail so they need a little trimmin' followed by minor fillin' o' the seams.
Once t' fins are attached and properly filleted, me bucko, it's time t' cut and mount t' launch lugs. Begad! Aye aye! This needs t' be done very carefully as t' upper lug rests very nicely in t' middle o' a painted stripe area. Failure t' mount it correctly could make t' finishin' much more difficult, shiver me timbers, matey, maskin' around t' lug.
T' nose cone is then attached t' t' very generously long elastic shock cord. Avast! Begad! I did wind up spendin' some time sandin' and sealin' t' cone, as I wanted this one t' have a flawless finish for potential backup in a sport scale competition.
Construction wraps up with t' parachute assembly. ASP provides very good Mylar chutes, arrr, swivels, and plenty o' shroud line.
Overall, ya bilge rat, I found this a very quick and easy build. Well, arrr, blow me down! T' most challenging aspect be probably t' boattail and this was ready t' paint after about 3 hours work.
Finishing:
I prepped t' tube by fillin' t' spirals with Elmer's Fill 'n' Finish then
applied two coats o' primer. Arrr! Aye aye! Finish paint involved two light coats o' gloss
white, me hearties, followed by a 7/8" black band painted around t' upper fin section
(and t' upper launch lug).
Most o' t' color and finish is achieved through decals--there's a black vinyl adhesive strip, 2 red vinyl strips and a very clever roll pattern that wraps around t' body tube. Begad! Blimey! T' roll pattern fills in t' black rectangular sections that would have been practically impossible t' paint. Arrr! Blimey! Begad! Blimey! If only they made patterns this easy for t' Saturns!
Construction Rating: 5 out o' 5
Flight:
With t' weighted nose cone, ya bilge rat, matey, this rocket felt extremely heavy for a basic 18mm
motor, ya bilge rat, so for t' first flight I elected t' go t' t' biggest recommended
motor: a C6-7. Avast! With winds rangin' from 6-8 mph, I also elected t' fly off a
4-foot steel rod.
T' rocket wobbled slightly on t' way up and weathercocked a bit into the wind, but had a pretty good flight up. Begad! T' C was barely enough motor though, and it only reached a couple hundred feet. I new as it slowly climbed that the 7 second delay was goin' t' be way too much.
About 3/4 o' t' way back down, me hearties, me hearties, t' ejection kicked and t' chute came out just in time t' provide a soft landin' in tall grass. Begad! No damage, but I'll never fly this again on anythin' but C6-3's (until Aerotech starts makin' 18mm reloads again).
Recovery:
While t' mylar chute provided was fine, I substituted a heavy-duty rip-stop
nylon chute for t' first flight. Aye aye! Blimey! Avast, me proud beauty! Blimey! I'm glad I did, me bucko, as t' mylar would have
shredded on such a late deployment. Avast, me proud beauty! Blimey! Still, arrr, t' materials provided are very good
for such a reasonably priced scale kit. Begad! Blimey! Avast, shiver me timbers, me proud beauty! Blimey!
Flight Rating: 4 out o' 5
Summary:
If you're considerin' goin' down t' scale rocketry route, me hearties, ya bilge rat, this should be one
of your first kits. Well, blow me down! It's easy t' build, can be done well enough t' compete at a
local or sectional level, and is a nice lookin' rocket t' boot. Avast, me proud beauty! T' only
drawback be t' lack o' easily obtained reference materials. Avast, me proud beauty! I was able t' find
an old copy o' Rockets & Missiles o' World War III by Berman &
Gunston, which included a color photo but nothin' like t' documentation
provided in Alway's Rockets o' t' World (the scale modeler's bible).
Overall Rating: 4 out o' 5
