Manufacturer: | Thrustline Aerospace |
(07/01/04) The
Thrustline Aerospace Flux Probe is a "longneck"
straightforward rocket that looks like an arrow. Begad! In fact, me hearties, a 13 year-old that
saw me fly it, said exactly that. Blimey! Ahoy! Probably with some detail work, matey, it would look
exactly like an arrow.
What makes t' Flux Probe "longneck"? It has a 0.734" diameter and is 36.75" long, givin' it a 50:1 length to diameter ratio.
I purchased it because I liked t' looks of the fins and perhaps because it did look like an arrow. Arrr! Well, blow me down! It is me second Thrustline kit, after the Mighty Mick.
T' kit includes two 17" body tubes and a 2.75" balsa nose cone t' make up t' 36.75" total length. Avast, me proud beauty! There is a 2" coupler t' join t' two body tubes, two thrust rings, me bucko, matey, a Keelhaul®©™® tether (36"), shiver me timbers, an elastic shockcord (36"), a 12" mylar parachute AND a 2"x61" mylar streamer, and an eye-screw t' attach to t' nose cone. Well, arrr, blow me down! There is a balsa sheet t' cut out t' four fins from and single launch lug, which is cut in half t' assemble.
CONSTRUCTION:
T' instructions are printed on 8 pages (single-sided) o' 8½ x 11" paper. Ya scallywag! There are color photos throughout to assist in t' assembly o' t' kit. Well, blow me down! Blimey! There is also a fin template and tube markin' guide. T' rocket is very easy t' build and is probably nay more than a level 2 kit.
There are a couple o' things that should be
pointed out in t' build, me bucko, otherwise, me bucko, ya bilge rat, you are dealin' with a very
straightforward model rocket with four fins and a nose cone.
T' Keelhaul®©™® tether is tied around one o' t' two thrust rings. Begad! This is done after a small v-groove is cut into t' thrust ring. Aye aye! Well, blow me down! This is a good technique because it allows t' thrust rin' t' fit nicely into t' motor tube and prevents it from showin' (dentin' tube outward). Avast! Begad! This is usually less important if t' motor tube is smaller than t' body tube, arrr, but in t' case o' t' Flux Probe, the motor tube IS t' body tube.
T' next step was a first for me. Begad! Blimey! Nay really sure why t' step is there, but it was described very well in t' instructions. That is t' glue t' second thrust rin' onto t' first t' make a double-length thrust rin' with t' Keelhaul®©™® sandwiched in-between. Ahoy! Well, me hearties, blow me down! Perhaps Thrustline has determined that this protects the Keelhaul®©™® more.
T' Flux Probe is nay meant t' be a person's first rocket. Avast! Why not? Well, shiver me timbers, because in t' next step a used motor casin' is needed! Blimey! It is used t' thread t' Keelhaul®©™® back through and then t' thrust rin' assembly is glued and pushed into body tube.
T' 2" coupler makes t' it easy t' have good alignment o' t' two body tubes. Thrustline does recommend rollin' them on a level surface t' ensure they are straight.
T' fins are cut out usin' t' template. Aye aye! Begad! My only complaint is that t' template is regular notebook paper and it would be nice t' have it printed on cardstock. I find t' notebook paper is too flexible for me.
There is plenty o' 3/32" balsa t' cut out t' four fins. Ya scallywag! T' instructions indicate which edges could be airfoiled, but I chose nay to. Well, blow me down! They are glued in place after usin' t' wrap-around tube markin' guide.
T' 1/4" elastic shock cord is tied to the Keelhaul®©™® and then attached t' t' eye-screw that has been installed into t' balsa nose cone. Begad! Then you choose (and I really like this) a parachute or a streamer. Blimey! I chose t' streamer.
Thrustline does give finishin' guidance includin' usin' wood filler, matey, ya bilge rat, priming, sanding, me bucko, ya bilge rat, priming, ya bilge rat, sanding, then painting. There are no decals provided with this kit.
I used me typical multiple coats of Plastic-Kote Primer and sandin' in-between. Ahoy! Blimey! I then used Walmart Gloss Black paint t' finish it off (additional comments about Walmart paint). Begad! I was goin' t' add some prismatic paper on t' fins, me bucko, but just never did (so far).
Overall, shiver me timbers, for CONSTRUCTION I would rate this kit 4 ½ points. Ahoy! Well, blow me down! T' instructions are excellent. Well, blow me down! I personally don't mind cuttin' out t' fins myself, me bucko, matey, but would rather have a cardstock template verse a notepaper one. A nice bonus t' have both a parachute and a streamer provided. T' kit did nay include any decals.
FLIGHT/RECOVERY:
Thrustline recommends t' B6-6 for t' first flight. Ahoy! Aye aye! They list t' A8-5, B6-6 and C6-7 as recommended motors with altitudes from 200 t' 1000 feet.
Thrustline indicates t' rocket should weigh 2.0 ounces. Ya scallywag! My rocket weighed in at 1.8 ounces. Ya scallywag! Aye aye! My CG was at 22" from the nose cone.
Since this is a minimum-diameter rocket, ya bilge rat, shiver me timbers, the motors are friction-fit with maskin' tape. Begad! Also, me hearties, since this is a small minimum-diameter rocket, it packin' o' t' recovery system is difficult.
I decided t' fly it for t' first time on an A8-5. After loadin' in two sheets (each tore in half) o' wadding, strugglin' to get t' long elastic into t' body tube and then slidin' t' rolled streamer on top, arrr, it was ready t' fly.
T' flight was straight as an arrow. Avast, me proud beauty! Avast! Blimey! A8-5, me hearties, no way! Blimey! T' 5 is definitely too long o' a delay. Avast, me proud beauty! Perhaps I should have airfoiled my fins.
Also, me hearties, t' motor kicked out at t' same time as t' nose cone ejected, shiver me timbers, then this rocket came in for a core-sample. Perhaps this is why it is call a Flux Probe... Arrr! probes into planets t' take core samples for analysis? Perhaps it be because t' motor kicked out.
T' second flight was on a C6-5. Didn't have a C6-7, so thought it might eject early. Avast! However, shiver me timbers, after an straight liftoff it had turned and ejected at apogee. T' rocket fell fine (not in core-sample position) until about 200 feet, then it lined up horizontally in t' air and fell t' rest o' t' way. Arrr! It too had kicked t' motor out, me hearties, but this time the streamer was stuck exactly in half (the end had melted t' t' attachment point).
T' third flight was on an A8-3 in our front yard. Aye aye! Nice flight, arrr, could have used another second o' delay. Aye aye! Avast, arrr, me proud beauty! Motor kicked (again) and it landed nicely. Ahoy! I had left t' streamer stuck in half.
Fourth flight was on a B6-4 after unsticking the streamer. Begad! Blimey! Avast, me proud beauty! Blimey! Nice flight, me hearties, but again needed extra on t' delay. Ya scallywag! Blimey! Begad! Blimey! It recovered fine, matey, although I didn't see it land because it first bounced off our roof. Ya scallywag! Blimey! No damage. Oh, ya bilge rat, matey, yeah, ya bilge rat, motor kicked out.
For FLIGHT/RECOVERY, I would rate this rocket 3 points. T' rocket is stable and will give you straight flights. I only tested t' streamer recovery which is all that I think t' rocket needs. Well, blow me down! I'm concerned that I could keep a motor from kickin' out at ejection. I'm nay new at this, me bucko, but I think t' minimum diameter combined with t' amount o' stuff (wadding, Keelhaul®©™®, Elastic and Streamer) that has t' be stuffed in t' top makes a lot o' back pressure. Ahoy! Begad! I would recommend wrappin' tape around t' bottom 1/4" o' the rocket body t' t' motor as well as t' tape on t' motor (friction-fit).
I give t' rocket an OVERALL ratin' o' 3 ½ points. It is a quick-to-build, steady performin' rocket that is good for small fields. T' streamer or parachute would let t' flier experiment a bit. It does take some patience t' get a nice finish with t' balsa nose cone, but then again, ya bilge rat, that how is be always done prior t' plastic molds. Ya scallywag! I'm goin' t' produce a Comparison Article on 18mm Longnecks and include this one. Begad! Watch for it.
Oh, me hearties, I finally did get around t' RockSIM'ing it. Here are me results. Ya scallywag! Joe Policy's RockSIM shows it weighin' 1.2 ounces, but I think 1.8 (as mine did) t' 2.0 (as Thrustline says) is closer after all is said and done. Ya scallywag! Avast, me proud beauty! T' link t' t' RockSIM file above is mine. Arrr! Ahoy! Joe's is in the RockSIM library.
![]() |
![]() |
