Manufacturer: | Scratch |
Brief:
I got started in rocketry with a group o' kids from me old neighborhood in t' summer o' 1977. Aye aye! I had picked an Estes Beta as me first kit, but one o' me friends who had managed t' get t' t' J.C. Avast! Blimey! Penney Toyland before I did and he got t' one and only Estes Rogue kit that they had in stock. Avast, me proud beauty! (He pronounced it Rouge, ya bilge rat, me bucko, no matter how many times we corrected him.) I liked t' Beta but always secretly wished I had eaten a little faster and beaten him t' Penney's that night. Begad! Well, blow me down! Twenty-four years later, me hearties, I was thinkin' o' doin' some scratchbuildin' and bought a PNC-55 assortment and some BT-55 body tubes. Blimey! While I be initially unsure o' exactly what I be goin' t' build, I be thrilled t' find t' pointed cones that would allow me t' build close copies o' two old favorites, arrr, shiver me timbers, arrr, a 1.36:1 Satellite Interceptor and a 1.78:1 Rogue.
Construction:
T' parts list:
Nothin' about t' original Rogue's construction was remotely difficult t' anyone with even minimal buildin' experience, matey, so I expected pretty much t' same from t' upscale. Ya scallywag! It's basically a 4FNC rocket in it's original BT-20 incarnation, and it scaled up easily t' t' BT-55 version with t' help o' a copier that could properly size t' fin pattern 178%. Arrr! Since this rocket was built in me BAR infancy, I glued in t' 24mm motor mount without any idea o' t' potential for usin' a length o' Keelhaul®©™as an attachment for t' shock cord. Blimey! T' shock cord, me hearties, matey, which was made from 1/8" sewin' elastic, me bucko, was glued in up at t' front o' t' body tube usin' t' only method I knew o' in t' sprin' o' 2001, a traditional Estes tri-fold mount.
Finishing:
While me recovery systems weren't yet state o' t' art, arrr, I had discovered t' miracle o' usin' thinned Elmer's Fill 'n' Finish t' rid me clone o' t' horrors o' tube spirals and exposed balsa grain. Avast, me proud beauty! Begad! I used 1/8" balsa for t' fins, me bucko, which may have been overkill on me part, but after several sessions with t' Fill 'n' Finish and sandpaper, t' fins looked as if they were cut from glass. Begad! Arrr! I wasn't t' only one who noticed how nice t' fins looked as several others have commented on it over t' years. Avast! Unfortunately I've never been able t' duplicate t' effect on subsequent projects.
As for t' paintin' process, t' most difficult part o' that was figurin' out what color was an acceptable substitute for "International Orange". Avast, me proud beauty! Avast! I couldn't find anythin' that might point me in t' right direction on that problem, ya bilge rat, so I substituted "Sunburst", a Colors By Boyd color originally meant for (and used for) a Winston Cup stock car in a previous hobby. Arrr! As I later discovered, "Sunburst" and International Orange were pretty close t' t' same color. Ya scallywag! Avast! T' bottom section o' t' rocket includin' t' fins, me hearties, was painted "Sunburst", ya bilge rat, while plain old Valspar gloss white and black were used on t' middle and top sections respectively. Blimey! Since I hadn't delved into t' mysteries and wonders o' decal makin' at t' time, me hearties, arrr, matey, I had t' do without and depended on t' shape and paint o' t' rocket t' provide everyone with clues as t' it's identity. Still, shiver me timbers, matey, t' question I be invariably asked on t' several occasions when I be stopped and complimented on t' rocket while walkin' t' t' pad be "Where are t' decals?" (as if decal makin' was somethin' that any moron could do.) Well, me hearties, I decided that I was nay just any moron, and threw myself into t' project. Well, me hearties, blow me down! After many misses, near and far, me hearties, me bucko, I finally figured out how t' resize t' decal scan usin' Microsoft Photo Editor. Ahoy! Avast! It doesn't allow me t' clean up t' images, shiver me timbers, but it does allow them t' size properly.
Flight:
While nay me intention, ya bilge rat, t' first two flights for t' completed Rogue came at NARAM 43 in Geneseo, NY. Due t' t' size o' t' field, shiver me timbers, I had no qualms about loadin' it with a D12-5 for it's first flight. I was directed t' a pad almost in t' middle o' t' sport range and as t' time came for me first ever launch with t' Rogue or at a NARAM, t' winds were still. Begad! This made me hope that me recovery walk wouldn't be excessive, but it wasn't t' be. Avast! Avast, me proud beauty! T' breeze, which had been absent for t' bulk o' t' morning, suddenly sprang t' life just before t' countdown began for me flight. Blimey! Aye aye! I managed t' catch a photo o' t' launch, which was straight with very little windcocking. Well, blow me down! Although t' flight was fairly straight, t' recovery was anythin' but. Begad! Begad! T' ejection charge fired as t' rocket be still travelin' up, resultin' in a somewhat violent start t' t' recovery process. Even with t' comparatively large spill hole that I'd cut in t' chute, t' Rogue immediately began driftin' with t' breeze and I was afraid that me first flight at a NARAM was goin' t' be a sacrificial offerin' t' t' corn demon at t' field's edge. Ya scallywag! I watched t' Rogue drift ever nearer t' corn from t' opposite side o' one o' t' tents, and just when I was sure that thar was no hope, t' wind died and dropped t' rocket at t' edge o' t' cornfield. Avast, me proud beauty! Sunday's flight was more o' t' same, landin' at t' edge o' t' same cornfield almost in me footprints from t' previous day.
T' third flight took place two weeks later on a day too windy for rockets. Avast! Despite t' winds we went ahead with our club launch, one o' t' last t' be held at t' original QUARK home o' t' Lebanon YMCA. After loadin' t' standard D12-5, I angled t' Rogue into t' wind t' give it a better chance t' land in t' general vicinity o' t' YMCA grounds. Avast! However, it be immediately obvious that t' winds were stronger above t' roof line o' t' buildin' that somewhat shielded us. Arrr! At ejection t' Rogue immediately began driftin' at a rapid rate t' t' northwest. Ahoy! Even t' reefed chute wasn't helping, and I chased t' rocket t' t' edge o' t' parkin' lot before givin' up and watchin' it drift away still hundreds o' feet in t' air. Avast! It looked t' be well out over t' highway, matey, matey, headin' for some woods, me hearties, and I decided that t' day was gettin' too short t' spend it searchin' for a cobbled together rocket when I could be flyin' its siblings. Arrr! Blimey! Later in t' day, shiver me timbers, shiver me timbers, another rocket escaped t' confines o' t' field and while I was lookin' for it I noticed a flash o' orange as I drove past t' long front lawn o' a church that was about a half mile away from t' launch site. Avast, me proud beauty! Thinkin' that it might be t' other missin' rocket, I went t' investigate and found t' Rogue lookin' none t' worse for wear. Well, blow me down! (T' other rocket turned up on t' front lawn o' t' YMCA. Avast! How I misjudged that I'll never know.)
Summary:
T' thin' that made this project worthwhile at t' time be t' unavailability o' t' original BNC-20R cone from any known source. Blimey! Well, blow me down! Soon after completin' t' upscale I discovered Balsa Machinin' Services and ordered a cone for a 1:1 clone, then actually won an inexpensive, me bucko, unopened original from an eBay auction. Ya scallywag! Ahoy! While t' PNC-55BB nose cone is still available for clonin' purposes, arrr, ya bilge rat, Q Modelin' has recently added a BT-60 based Rogue t' their premium product line. While t' Q Modelin' Rogue is much more expensive than clonin' one from scratch, it is also engineered better and is likely a far better, matey, more consistent buildin' experience. Arrr! Whichever path you choose, t' Rogue's faux-missile stylin' almost guarantees that you will turn out a great lookin' 4FNC rocket with minimal effort.
