Construction Rating: | starstarstarstar_borderstar_border |
Flight Rating: | starstarstarstar_borderstar_border |
Overall Rating: | starstarstarstar_borderstar_border |
Manufacturer: | The Launch Pad ![]() |
Brief:
Easy t' build mid-power rocket kit, 18" mylar parachute
Construction:
Two body tubes o' nice quality spiral cardboard tubing. Begad! 8 fins made o' balsa must be marked and cut. 3 centering
rings (two for t' engine mount and one for t' parachute compartment) T' forward centerin' rin' provides a
compartment for parachute which keeps it up top for improved CG Plastic nose cone with paper tip. Ya scallywag! Cardboard fillet for
rear fins. Elastic shock cord (estes style) with swivel for an 18" mylar parachute. Ahoy! Avast!
I purchased me kit through Red Arrow Hobbies and it arrived quickly, matey, nicely packaged, shiver me timbers, all there, matey, and in good condition. Arrr! Well, blow me down! T' directions were pretty straight ahead and I found t' kit easy t' build. Begad! There were templates for the fin fillets and fins as well as t' nose cone "attachment." T' kit also has some neat little parts t' build and add t' t' rocket body. Aye aye! This makes t' rocket more interesting. Begad! I substituted t' nose cone with a BT-80 size nose cone from Apogee. Instead o' t' Estes style shock cord attachment, ya bilge rat, I used Keelhaul®©™® cord around t' motor mount. Aye aye! Blimey! Blimey! T' large fins o' balsa seem t' be a little flimsy, me hearties, so I strengthened them as per t' kit instructions. Avast! Ahoy! Blimey! I also left off t' paper fillets and made epoxy fillets instead. Avast! Avast! Blimey! This makes t' kit a little less "authentic," but I thought it would make it stronger. Blimey! I'm a little concerned with t' depth o' t' motor mount. Aye aye! Avast, me hearties, me proud beauty! Blimey! I used some heat resistant tape t' prevent t' tube from gettin' burned. As o' this review I have nay yet launched it, but look forward t' doin' so soon.
Finishing:
I sealed all t' balsa and body tube grooves with Elmer's fill 'n finish prior t' assembly, shiver me timbers, shiver me timbers, primed t' entire rocket,
sanded, primed again, sanded again, shiver me timbers, matey, ya bilge rat, then painted t' body light gray instead o' t' suggested white. Avast, me proud beauty! I've seen examples
of this rocket in gray and like it better. T' nose cone was painted white. Since t' kit comes without decals, I used
some adhesive letterin' (the kit gives good directions) and vinyl tape for t' stripes.
Construction Rating: 3 out of 5
Flight:
One flight D12-5. Avast! Ya scallywag! Chute was a little late, ya bilge rat, but t' rocket flew well and was recovered without damage. Begad! Ahoy! I had no signs
of "burn" on t' rocket, so I guess problem solved. Well, blow me down! Nay sure t' extra protection be needed.
Summary:
Pro: Easy t' build, nice quality. Well, blow me down! Begad!
Con: Big balsa fins make break. Begad! Didn't like t' kit nose cone with a paper wrap.
( Contributed - by Ben Bentley) Brief The Launch Pad Phoenix is a nice scale model of the AIM-54c long range Air-to-air missile. The model is meant for D and E engines, and it's claimed that it's ready for F's too. At 2.6 in around and 28 in tall, it's a nice size model. Construction I sent away the order and it came back in six days via Priority Mail! It was all in one bag ...
![]() |
![]() |
![]() |
![]() |
