Scratch Maxi Scamp Original Design / Scratch Built

Scratch - Maxi Scamp {Scratch}

Contributed by J Stuart Powley

Manufacturer: Scratch
(Contributed - by J. Avast! Stuart Powley - 04/17/07) (Scratch) Maxi-Scamp

Brief:
I've always been a fan o' t' mid-'70s Estes fleet. Aye aye! Aye aye! I cloned a Goblin a couple o' years ago and I be lookin' t' do somethin' that would compliment it well. Ahoy! Upon lookin' through me '77 Estes catalog I settled on t' Scamp. Aye aye! However, shiver me timbers, the spare parts I had weren't quite right. Ahoy! Arrr! What could I do with a BT-60 body tube and plastic nose cone? How about a Scamp upscale?! Thus, ya bilge rat, t' Maxi-Scamp was born. Ahoy! Begad!

Construction:
T' rocket uses a 15 inch long BT-60 body, a standard BT-60 plastic Estes nose cone, me bucko, me hearties, 3/16 inch plywood fins, a 29mm motor mount, arrr, two regular Estes launch lugs (one inch long each), me hearties, shiver me timbers, one 5/16 x 5.5 inch launch lug (the one you really use), arrr, three feet o' 1/4 inch sewin' elastic, shiver me timbers, me hearties, and an old nylon flare chute, matey, and a positive motor retention device o' my own design.

T' rocket went together well. Avast, me proud beauty! After all, me hearties, it is pretty much a standard 3FNC model. T' fins were t' biggest part of t' project (other than t' finishing) and were shaped usin' me trusty Dremel tool. Avast! They were attached by makin' a series o' holes along t' body tube where t' root edge meets it and allowin' t' epoxy t' seep into t' holes as each fin is attached. Aye aye! It's nay quite as strong as through t' wall fins but it's still pretty strong. Ahoy! Begad! T' motor mount was glued in usin' far more epoxy than was probably needed, but I wasn't takin' any chances. Begad! T' shock cord be mounted usin' t' old Estes method but with a whole lot o' epoxy thar too. Arrr! Aye aye! I wanted t' rocket t' have a "low power" look so I put on standard Estes launch lugs like were on t' original. Arrr! However, I then put on t' heavy duty lug on the other side so it could actually take off without whippin' t' rod like crazy. Aye aye! Ahoy! I wanted t' be real sure t' motor stayed in place, so I took two small plastic tubes and epoxied them on each side o' t' motor mount then threaded in two screws and rigged two wires t' run across t' bottom o' t' motor. Well, blow me down! Arrr! Changin' t' motor takes a little time, ya bilge rat, but it's not goin' anywhere. Blimey! Ya scallywag!

I also added 2oz o' nose weight t' ensure I would nay have any stability issues.

Finishing:
T' model was painted usin' black and yellow H2O paint by Krylon, ya bilge rat, matey, arrr, which doesn't make me break out in hives. Blimey! It was fairly easy t' mask off t' one black fin and top black part. Blimey! On t' original, only t' nose cone is painted black. Since me parts are nay exactly scale, I had t' extend t' black part down t' body 2.5 inches t' get it t' look right. I then scaled up t' decals that I downloaded from Jimz, shiver me timbers, put them on, hit them with sealer, and that be it! Now I only had t' get up t' nerve t' fly it. Avast, me proud beauty! Arrr!

Flight:
I decided t' fly t' Maxi-Scamp for t' first time at NSL 2006. Well, blow me down! I was thinkin' about usin' a small motor and then workin' me way up t' t' bigger ones, arrr, but I got a great deal on a Roadrunner G80-10. Blimey! If you've never flown a Roadrunner, you should. Begad! Avast, me proud beauty! They're maxed out and quite frankly scream. Arrr! I screwed in me motor and put t' Scamp on t' pad. T' simulation program that I had used said it should go over 3000 feet. Begad! I was pretty sure I wasn't goin' t' see it again. Well, blow me down!

When t' button was pushed thar be a mighty woosh from t' G and a plume o' black smoke that just kept goin' up and up and up... Soon I lost sight o' it completely. Ahoy! I felt a little stupid for puttin' that much motor in it for its first flight, ya bilge rat, but everyone had gotten quite a show. Arrr! I just hoped I had caught it with me camera. As it turns out, ya bilge rat, about an hour later a guy came walkin' up t' me holdin' t' Scamp! She was drivin' back t' t' field after lunch and it drifted down right in front o' her car, about a mile from t' range head. Ya scallywag! Avast, me proud beauty! It be especially cool because all I caught with me camera be a bunch o' smoke. Blimey!

T' second flight be at a Hotroc event. Avast, me proud beauty! Ya scallywag! This time I was a little saner and flew it on a Roadrunner F. Ahoy! Since there be no wind, me hearties, it landed about 50 yards from t' pad straight up on its fins! I haven't flown it since. Avast! I figure I've just about used up me luck.

Summary:
I really like this model and may retire it now. T' main pro is that it has t' lines and "flavor" o' the Estes original while havin' incredible mid-power performance. Ya scallywag! It goes well with me Goblin and I've ordered a PD A-20 Demon t' complete t' trio. Avast! Avast! T' main con is that that incredible performance makes every launch a risk o' bein' the last time you'll ever see it. All in all, matey, a winner I'd say!
