Quest - Viper Rocksim Design File

• Manufacturer: Quest
• Motor Size: 18 mm
• Power: Low-Power
• Recovery: Parachute
• Skill Level: 1
• Style: Sport

Comments: Parts were weighed and measured individually for this design. The sum of the weight of the 1) Plastic Fin Unit, 2) Launch Lug, and 3) Viper Fin Set equals the actual weight of the Plastic Fin Unit.

Designer: Quest

Download Quest_Viper.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Quest - Viper {Kit} (5594)
Diameter: 0.9840 inches
Style: Sport

Parts Breakdown

• Quest Ogive Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 14.00 in]
• Quest Polyethylene LDPE Parachute (14.00 in)
• Quest 50053 Elastic Chock Cord Mass Object
• Quest 50012 Quest Kevlar Shock Cord Mass Object
• Quest Polycarbonate Ring (0.9800 - 1.0840 in)
• Quest Polycarbonate Launch Lug (0.1720 in)
• Quest Polycarbonate Freeform Fin Set
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 2.70 in]
• Quest Paper Ring (0.7400 - 0.7500 in)
• Quest Paper Ring (0.7400 - 0.9450 in)
• Quest Paper Ring (0.7400 - 0.9450 in)
• Quest 49000 Motor Clip Mass Object
