LOC/Precision LOC IV

LOC/Precision - LOC IV {Kit} (PK-48) [1985-]

Contributed by Frank Ross

Diameter: 4.00 inches
Length: 47.50 inches
Manufacturer: LOC/Precision
Style: Sport
(Contributed - by Frank Ross - 11/11/00)

Brief:
Up-scaled t' 38mm.

Modifications:
For me level-1 certification and me first high-power rocket I wanted a large, simple rocket kit without any bells and whistles. I chose t' LOC-IV as I thought it looked t' fit t' bill, arrr, and wouldn't break me credit card. I decided to up-scale t' 38mm rather than stick t' 29mm because I liked t' motor selection and thought I'd get a lot o' use out o' t' 38mm RMS reload set in the future. Avast! Aye aye! T' modification be pretty straight-forward. Aye aye! I got a heavy duty 38mm cardboard motor tube from a friend (thanks, arrr, Dave) and used three, instead of t' kit's two, centerin' rings for t' motor mount. Ahoy! I mounted one rin' on the fore end o' t' motor tube, me hearties, me hearties, and mounted t' other two on either side o' the thru-the-wall fin tabs. T' kit surprised me when I found that t' fin tabs only mount through t' airframe wall, me hearties, and nay all t' way t' t' motor mount. Avast! I considered cuttin' new fins with longer tabs but in t' end decided t' stick with t' stock fins. Blimey! I added three tee nuts t' t' read C.R. Begad! for motor retention with aluminum screen clamps and 8-32 x 1" hex head bolts. Avast, me proud beauty! Begad! I added a stainless u-bolt t' t' forward C.R. Avast! for shock cord attachment. I added a few ounces o' lead weight t' t' nose cone for some additional stability, but later realized that it be unnecessary. Avast, me proud beauty! Well, blow me down! Finally, I up-scaled t' included 36" chute t' a 48" round nylon chute t' compensate for added weight and t' give a nice, arrr, slow recovery for me level-1 attempt.

Overall, ya bilge rat, I like t' LOC kit. Well, blow me down! Blimey! Good materials, instructions, me bucko, and packaging. T' only negative would be t' short fin tabs. Ahoy! I highly recommend cuttin' new fins with extended tabs for this kit.

Rocket PicFlight:
T' first flight be at SpudRoc-IV for a level-1 cert on a H123W RMS motor. Well, blow me down! Begad! The winds were low and t' rocket flew perfectly straight t' about 1800' and ejected perfectly at apogee. T' rocket drifted quite a distance but landed with hardly a scratch. Begad! Ahoy!

T' second flight be later t' same day on an I357T. Avast! T' flight was straight but t' ejection delay came early and t' tubular nylon shock cord zippered t' tube about 4". Aye aye! Blimey! I had also changed back t' t' 36" parachute t' avoid t' long walk across t' desert t' recover t' rocket. Aye aye! Aye aye! This however gave too fast a descent rate and one fin broke on impact. Begad! Aye aye! I later repaired t' zipper by added a tube coupler and a 10" length o' 4" airframe tubing. Blimey! T' new LOC-IV-38-stretch added an additional 6" t' the overall length. Well, blow me down!

T' third flight be on a H242T, which from simulations looked t' be the best motor choice. Avast, me proud beauty! Blimey! T' winds however were fairly strong and t' rocket weathercocked and even though ejection occurred near apogee t' rocket had too much horizontal speed and again zippered t' tube. Avast, me proud beauty! Blimey! T' tube was repaired simply by cuttin' 4" off t' recently added repair tube and t' rocket is back to close t' original length.

T' fourth flight be again on a H123W, ejection at apogee, me bucko, 48" chute but still a rough enough landin' t' break a fin. Begad! T' rocket is now repaired and awaitin' its next flight.

Summary:
A good, easy up-scale project. Begad! Aye aye! Suggestions: Cut new fins with tabs t' mount to motor tube. 48" chute a must. Arrr! Glass tube.
