Construction Rating: | starstarstarstar_borderstar_border |
Flight Rating: | starstarstarstarstar_border |
Overall Rating: | starstarstarstar_borderstar_border |
Manufacturer: | Estes ![]() |
Brief:
This be t' Estes BT-80 sized V2 that was recently re-issued. Aye aye! It is a 1/25 scale model o' a production V2. It has significantly over-sized fins for stability purposes, and a minimal amount o' scale detail. It flies on a 24mm motor, recommended t' be a D12-5, although most will look for more power.
Construction:
T' components are typical Estes, me hearties, which is largely pretty good. Ahoy! Blimey! T' body tube is a standard BT-80. T' nose and tail cones are rotational molded plastic. Avast, me proud beauty! This is done reasonably well with visible, matey, but acceptable, shiver me timbers, mold lines. Begad! T' tail cone has a significant discontinuity ridge near t' tenon and also is nay entirely fair, me bucko, showin' a significant concavity right near t' fin leadin' edge. T' nose cone is nay really very accurate, bein' a bit too short and has a rounded tip. Ahoy! T' round I chose t' model was White Sands round #56 which had a pointy nose, as do most.
T' shock cord attachment is a molded plastic loop, me hearties, which as you will see later, was nay t' brightest thin' in t' world. Begad! T' recovery system is also typical Estes, with a plastic parachute. Arrr! T' shock cord be t' usual absurd 1/8" short elastic cord, me bucko, ya bilge rat, which lasted about 2 seconds after I opened t' package. Avast! Begad! I replaced this with 3/8" sewin' elastic, arrr, 3 feet long.
T' fins are die-cut balsa. Begad! T' wood in me kit was typical "rocket wood"- about 15 lb/cu ft c-grain. Avast, me proud beauty! This was satisfactory and I used it, shiver me timbers, me hearties, but t' model could be lightened significantly with lighter wood. Avast, me proud beauty! T' centerin' rings and motor mount are also t' usual Estes components, with fiber centerin' rings and a BT-50 motor mount. Ahoy! These might seem a little minimal for somethin' that's likely t' get E's and low F's, ya bilge rat, ya bilge rat, but t' fins go through he tail cone all t' way t' t' motor mount tube, and t' whole assembly is very well braced even stock.
T' decals are typical water transfer types (in mine, me bucko, arrr, at least). They are minimal but appropriate for a production model.
T' kit is fairly easy t' build. Avast! Ahoy! It's pretty standard except for t' tail cone/fin/motor mount assembly. Avast! Aye aye! T' slots for t' fins are molded into t' tail cone but nay cut through. Well, blow me down! Avast, me proud beauty! Cuttin' through this is a tricky operation. Begad! If you just cut it off flush t' slot would be far too wide. Blimey! This is a problem if you do nay plan t' add large fillets. I started out cuttin' t' top o' t' molded fin slots just far enough down t' get through, me bucko, arrr, and then spent about 2 hours with a file widenin' them t' just 1/8" for t' fin. Avast, me proud beauty! You have t' very careful doin' this t' avoid gettin' t' fins on crooked later. In retrospect, ya bilge rat, I would probably make a jig for this operation. Avast, me proud beauty! Ya scallywag! Once this tricky operation is done, matey, then t' TTW tabs on t' fin have t' be very carefully fitted t' just touch t' motor mount tube. Avast! They are all longer than necessary, and they need t' be sanded very carefully down t' get t' root edge that bears on t' tail cone just touching. Well, matey, blow me down! It's nay too hard t' do, but it's a little fussy. Avast! Don't take off too much! Both o' these operations are critical t' get a good fin/tail cone fit. Aye aye! T' good news is that once it all fits together, its pretty darn sturdy, me bucko, even without fillets.
T' rest o' t' construction is pretty straight-forward. Ya scallywag! Ahoy! I did a little extra detailin' o' t' fins and engine area on me model. Ahoy! I looked at a bunch o' pictures from Rockets o' t' World and other sources t' get a good visualization o' t' fin shape, and sanded this in. Arrr! T' fins are pointed on all edges, and expand t' full width in about 1/4" on this sized model. Blimey! I also added 1/64 ply shrouds at t' base o' each fin t' support t' end o' t' fillets. Blimey! Begad! This be t' area where t' jet vanes go into t' base o' t' fins. I suggest studyin' t' pictures very carefully in this area t' get an idea how this looks.
Another thin' I did was t' cut t' aerodynamic surfaces loose from t' fins, finished these separately, then glued them back on. Ya scallywag! Blimey! This gives a good representation o' their function. Aye aye! Blimey! I also added t' control push-rod fairings. Well, blow me down! Blimey! Arrr! Blimey! I made these out o' 3/32 basswood.
An additional modification I made was t' make a conical nose tip from .010 styrene sheet, and glued it t' t' tip o' t' nose. Begad! This gives it t' desired point, but is weak enough t' deform if it hits someone. Ya scallywag! Also on t' nose, arrr, I scribed t' hatch outlines into t' plastic with a bare metal foil scribe. Well, blow me down! This was specific t' me particular round.
Finishing:
Finishin' be pretty simple. I used Squadron White putty t' finish gettin' rid o' t' mold lines and t' tail cone joint. Avast, me proud beauty! Ya scallywag! Blimey! One thin' pretty lackin' on t' kit be t' prominent fillets at t' fin/body joint. Aye aye! Blimey! Leavin' this off would make it very "model-like". Examination o' t' photos indicates that this fillet is sort o' conical, me bucko, matey, which a very tight radius at t' LE and pretty wide at t' TE. This precludes usin' a tool t' make it. I used AeroPoxy Light filletin' epoxy t' make t' fillets. Ya scallywag! Blimey! I put down t' blockin' tape in a rough triangular footprint t' try t' get t' conical look. Ya scallywag! Then I applied t' material, matey, and just eye-balled t' cross section while shapin' with me finger and a bunch o' water. Begad! Blimey! It's sort o' like clay sculpturing. Blimey! T' fillet ends at t' tail on t' 1/64 ply inserts I added. Ahoy! Blimey! Do them one at a time and it can be done. Ahoy! A little sandin' when hard t' fair them in t' t' fins/tail cone and it comes out pretty good.
I used K&B UltraPoxy primer over t' whole model, ya bilge rat, which sealed everythin' up well, and filled t' last o' t' little pits left here and there. Blimey! Avast, arrr, me proud beauty! T' round I was modelin' was mostly white with a black roll pattern, matey, and some bare metal details. Avast, arrr, me proud beauty! I painted t' whole model white with K&B SuperPoxy. Arrr! I then masked off for t' fins and shot them with SuperPoxy black. Well, me hearties, blow me down! I did t' roll pattern in 3 separate maskings - top and bottom rings first, ya bilge rat, arrr, then t' diagonal lines tilted t' t' left second, arrr, and t' diagonal lines tilts t' t' right third. Avast, me hearties, me proud beauty! You could do it all at once, but then t' tape overlaps might be a problem. I used 3M fine line green tape for all masking.
For t' bare metal nose, I sprayed SNJ Spray metal with me airbrush. Avast, me proud beauty! This works great and is pretty durable compared t' some o' t' other metal paint. Well, blow me down! For t' bare metal around t' hatch, me bucko, me hearties, I used Testors aluminum paint in a #1 Rapidograph pen. Nay surprisingly, me bucko, this got clogged up a bunch o' times, matey, me hearties, and be a real pain. Arrr! Blimey! But I can't think o' a lot o' better ways t' get such a fine line. Arrr! Panel lines were done with Rapidograph pens usin' black ink over t' white sections. I started out with white ink for t' black sections, but this skipped so badly and was so fragile t' handle that I mixed up some medium gray usin' a combination o' white and black. This be a little better, me bucko, and was a little more subtle.
I clear-coated t' whole model with PPG DAU75 automotive acrylic urethane with DXR80 hardener. This stuff goes on so easy it almost makes is worth t' exorbitant price. Avast! Almost. Arrr! Begad! It makes it very shiny, ya bilge rat, which isn't all that accurate, me bucko, but it looks cool.
To finish off, I made some antennas out o' .014 stainless wire (left over model airplane control lines...), shiver me timbers, and glued them t' t' fin tips. Ya scallywag! These are surprisingly tough, shiver me timbers, they get twanged all t' time but they usually sprin' back.
Construction Rating: 3 out o' 5
Flight:
T' recommended motor for this model be t' D12-5. Begad! Ahoy! Since I have a bunch o' 24mm RMS reloads, I haven't tried it with t' D12. I have flown it on t' E28-4 (really 2) and it moves out quickly, arrr, and ejects at about 200 mph. Blimey! Blimey! After that I replaced t' shredded plastic parachute with an Estes nylon 18" chute. T' D15-4 works well, ya bilge rat, shiver me timbers, shiver me timbers, and has a nice high-enough flight. Avast, me hearties, me proud beauty! T' E15-4 SU also works well, shiver me timbers, and gets it very high! T' 18" chute is plenty big enough, and it drifts pretty good. Ahoy! T' only damage I've had was from some kids findin' and throwin' it back and forth like a javelin into a gravel pile.
Recovery:
As mentioned earlier, t' stock shock cord is laughable and be replaced. T' 3/8 elastic seems t' be plenty good. Well, blow me down! T' stock chute is also OK if you avoid off-apogee ejection. Ya scallywag! Well, blow me down! This model also takes a lot o' waddin' and this leaves relatively little room for chute packing. Aye aye! T' nose cone loop broke on t' first flight. Blimey! I replaced this with some .018 stranded SS cable threaded through some holes I drilled in t' base o' t' nose cone. Arrr! This seems t' be holdin' OK. A potentially better way t' go would be t' glue a 1/8 ply bulkhead into t' base o' t' nose cone. Avast! Begad! It needs some nose weight anyway.
Flight Rating: 4 out o' 5
Summary:
All in all, me hearties, a pretty good sport scale model as it comes, me hearties, with t' basis for a decent precision scale model with some modifications and cuttin' down t' fins t' scale size. Avast, me proud beauty! Avast, me proud beauty! Blimey! Pros - flight performance, arrr, reasonable size, and price. Cons - tricky fin attachment, me hearties, me bucko, inadequate shock cord, shiver me timbers, lack o' fin details.
Overall Rating: 3 out o' 5
![]() |
![]() |
