Arcas Rocksim Design File

Contributed by Michael Smeltzer

• Manufacturer: Rocket R&D

Designer: Rockect R&D

Download oop_r&d_hv_arcas.rkt

To use the design file above, you need a copy of Rocksim, a rocket design and simulation program.

Kit Name: Rocket R&D - HV ARCAS

CG: 61.1332 inches from front
CP: 80.4711 inches from front
Margin: 4.83 Overstable

Parts Breakdown

• Arcas Ogive Nose Cone
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 11.00 in]
• Public Missiles Ltd. PML CT-3.90 Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 34.00 in]
• Public Missiles Ltd. PML CT-3.90 Ring
• Public Missiles PML BP-06 Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 34.00 in]
• Public Missiles PML BP-06 Ring
• Public Missiles PML BP-06 Ring
• Public Missiles PML BP-06 Ring
• Custom Estes BT 1090 1.0173 inches 25.84 mm 0.7250 inches 18.42 mm 0.7250 inches 18.42 mm 0.9500 inches 24.13 mm 0.9500 inches 24.13 mm 0.2400 inches 6.10 mm 0.0000 inches 0.00 mm 1.5950 inches 40.51 mm 2.5550 inches 64.90 mm 1.8000 inches 45.72 mm 1.5200 Body Tube [Length: 11.00 in]
• LOC LOC LL50 Launch Lug
• Custom Mass Object
• Arcas Freeform Fin Set Freeform Fin Set
• Custom Rip stop nylon Parachute (48.00 in)
• Public Missiles PML BP-06 Ring
• LOC LOC LL50 Launch Lug
