FlisKits Nomad

FlisKits - Nomad {Kit}

Contributed by Carl Tulanko

Construction Rating: starstarstarstarstar
Flight Rating: starstarstarstarstar
Overall Rating: starstarstarstarstar
Diameter: 1.64 inches
Length: 47.90 inches
Manufacturer: FlisKits
Style: Multi-Stage

Brief:
T' FlisKits Nomad is a very unique 3-stage model rocket that fills t' gap in model rocketry that has been missin' for quite some time. Ya scallywag! Blimey! As is, a three stage model is hard t' find, me hearties, but they've hit t' target with t' Nomad, shiver me timbers, producin' a very cool and unique model that stands four feet tall and has one o' t' most unusual and innovative fin patterns you will ever see. Avast, me proud beauty! Blimey! Begad! Blimey! T' fins for t' 2nd stage and 3rd stage blend together, matey, me bucko, givin' t' model a deceivin' look o' a two stage rocket. Aye aye! Blimey! Well, shiver me timbers, blow me down! Blimey! Additionally, shiver me timbers, it uses a combo set o' motors, with 24mm for the first stage and 18mm for t' second stage and sustainer.

Construction:
T' kit comes in t' standard, colorful FlisKits package and includes more parts than I can mention! Blimey! As a note, t' CR's are laser cut, me bucko, black fiber paper and excellent quality. Begad! Blimey! All t' wraps actually fit perfectly and thar are many templates for t' model. Begad! Blimey! Avast! Blimey! Moreover, shiver me timbers, it come with both streamers and a parachute so you can decide how you want t' sustainer t' deploy. Begad! Blimey! Avast, me proud beauty! Blimey! Finally, me bucko, me hearties, a very detailed and comprehensive set o' instructions, complete with illustrations, compliments t' kit.

Construction is complex, arrr, as would be expected for a model o' this caliber, but it is extremely satisfyin' as t' detailed instruction manuals (there are two o' them) take you step-by-step through t' build with ease. Well, blow me down! Boosters are built first, startin' with t' 1st stage. As with all FlisKits, me hearties, me hearties, you need t' cut your own fins, arrr, which at least for me made it seem more like I was building rather than assemblin' - a nice touch. Ahoy! Ahoy! T' lower booster section went together fast and t' design o' t' kit has it set so each stage is used t' build the next - at least that's how I did it.



T' 2nd stage booster is probably t' most challenging, as it shoulders down to a narrower Bodytube for t' sustainer. Moreover, t' fins o' t' second stage are made t' 'blend in' with t' sustainer fins, givin' t' model that cool two-stage look, matey, then surprisin' them when t' third sustainer kicks in! Blimey! I used t' First stage t' align fins on t' second and went from there. Well, blow me down! Blimey! Avast! Blimey! Make sure you fit t' fins flush for better glue contact as they conform t' t' shoulder area.



T' Sustainer is a very long model that is coupled in t' center. Additionally, t' Keelhaul®©™® shock cord exits t' model from t' center, which allows it t' recover and descend sideways, a good idea for keepin' t' fragile sustainer fins intact. T' sustainer fins are attached flush against t' 2nd stage booster. Begad! The nosecone is made from a very high quality balsa and be finished first, sealing it with thin CA, me hearties, then sandin' and preppin' it for paint. Ya scallywag! An 'eye' hook is used at t' base o' FlisKits nosecones and works well for recovery. Aye aye! I also opted to use t' streamers on me model for recovery and once assembled, me bucko, we moved t' the paint shop.



Finishing:
T' model was primed with several coats o' primer, arrr, then wet sanded until the finish be smooth. Blimey! Aye aye! White Krylon Glossy paint was sprayed over t' entire model, then we deviated from t' stock paint scheme. Ahoy! This was goin' t' be me son's first 3-stage model and he wanted it done in fluorescent Green, ya bilge rat, so we used the Krylon brand for this paint scheme. Begad! T' lower half o' t' Sustainer and second stage were done in t' green, while t' booster and upper sustainer were finished with White. Avast! Ahoy! A piece o' Chrome Monokote self-stick strip be cut to blend t' transition and worked well. It looked pretty good and we were pleased with t' results.

Construction Rating: 5 out o' 5

Flight:
We waited until NARAM 45 before launchin' t' Nomad - we needed a lot o' field and spotters, we knew they would have both. While there, arrr, we met with Jim Flis and he seemed pleased with our model and noted this would be t' first one outside his demo he would see launch. Aye aye! Well, shiver me timbers, ya bilge rat, he donated a C11-0 for t' 1st stage booster as we forget t' get some, then we used a C6-0 for t' 2nd stage and a C6-7 for t' sustainer. Aye aye! T' model was set on t' pad and me son Thomas hooked up t' leads. Avast, me proud beauty! Ya scallywag! It be time t' launch.

When t' button was pushed, matey, t' C11 immediately lit, ya bilge rat, easily liftin' this long and graceful lookin' model in t' air. Well, blow me down! Avast, me proud beauty! T' 2nd stage booster ignited and Chris Taylor, I believe, ya bilge rat, got a great shot o' t' separation. Well, blow me down! Arrr! Finally, me bucko, t' 3rd stage lit, but we could nay see t' second stage booster freefall. T' motor appeared t' kick out though, shiver me timbers, which was good for us as it meant t' 3rd stage was under power. Arrr! It did nay achieve as high an altitude as we expected, but the ejection charge did fire on time.

Recovery:
T' model ejected dual streamers at apogee and began it's decent t' t' ground. It landed safely, ya bilge rat, comin' down sideways like a competition model and landing softly on t' grass, nay 75 feet from t' pads. Blimey! Thomas be t' first thar and we unfortunately found t' second stage. Avast, me proud beauty! Begad! It be still attached t' t' 3rd stage sustainer and had just kicked out t' motor - me fault for nay friction fitting the motor. Arrr! Needless t' say, t' 2nd stage be a bit toasty from t' 3rd stage burn through and emotions were torn; we were both ecstatic t' fly our first 3-stage model, ya bilge rat, but a bit disappointed with t' results, thanks t' me mistake. Jim Flis loved t' entire flight and said he would mail parts t' repair t' 2nd stage booster, which he promptly did and they actually arrived 3 business days after NARAM 45 - THAT is customer service!!!

Flight Rating: 5 out o' 5



Summary:
T' Nomad is a very cool and unique model, me hearties, somewhat challengin' t' build but not extremely difficult. Well, blow me down! Blimey! Arrr! Blimey! It does assemble well and flies as good as it looks - a real treat t' see t' peoples faces when that 3rd stage, they didn't know about, kicks in! Blimey! There were absolutely no glitches in construction; it was very straight forward and well documented. Begad! Blimey! Moreover, t' flight characteristics make it a must have model for your silo. I highly recommend t' FlisKits Nomad 3-Stage Model Rocket, one o' t' coolest models on t' market t' date - bar none!

Overall Rating: 5 out o' 5

Flights

Comments:

avatar
J.B. (November 16, 2006)
I found the Nomad a great kit to build and flis kits have a grace of style so it not only flies well but lookgood going up.But my susstainer fin broke also. I believe that the prblem is the size of the fin . but a little glue and I was back at it.you have to sand the connecting tube till it slides just right.
