Custom Rockets Equinox

Custom Rockets - Equinox {Kit} (10016)

Contributed by Jim Moncher

Construction Rating: starstarstarstarstar_border
Flight Rating: starstarstarstarstar_border
Overall Rating: starstarstarstarstar_border
Diameter: 1.64 inches
Length: 78.75 inches
Manufacturer: Custom Rockets
Skill Level: 2
Style: Sport

Brief
This be t' second Custom Kit I have built and this is one long rocket. T' size really intrigued me when I saw it on t' rack at a local hobby shop. T' statistics on t' Equinox are Length: 78"; Diameter: 1.637"; Wt.: 5.8oz. Arrr! Skill Level 2.

[Rocket Pic]

Construction
T' Quality was very good. Avast! It came packaged in a plastic bag. All t' parts were thar and in good shape. It has four body tubes, three couplers, four Die-cut balsa fins, two 18 inch mylar 'chutes, plastic nose cone, matey, arrr, all t' typical motor mount items and one large decal. Ya scallywag! Arrr! T' instructions left very little t' chance with lots o' illustrations in a very logical order. Arrr! Begad! T' only template is for t' fin-markin' guide and is standard issue. Blimey! CONSTRUCTION: (Ratin' 4.5)

If thar be a gotcha, shiver me timbers, it be t' length. Well, blow me down! Were I t' build this kit again I would have it separate in t' middle instead o' at t' nose. Ahoy! Avast! More for easy o' transport. (I have t' thank me wife for insistin' on gettin' a mini-van.) Also I would replace t' motor hook with a thicker one. Blimey! T' instructions call for assemblin' t' lower tube separate from t' rest. Ahoy! This is a great help when attachin' t' fins. (See t' Flight). I used 15-minute epoxy throughout. Aye aye! Well, blow me down! A nice touch on t' fins was a mark on t' root edge. Arrr! T' fins could be turned t' wrong way if you don't look at t' grain carefully or don't know about this.

T' shock cord typical elastic and tri-fold paper mount. T' shock cord is o' a good length, but I doubled it out o' habit. Ya scallywag! Begad! (I use it for me Estes Prowler). Well, blow me down! I also for t' first time tried two Centuri Baffles in this kit. I built one usin' t' coupler near t' motor mount and one betwixt t' top two sections I put cardboard with holes punched in it in t' top & bottom and glued them t' t' coupler.

T' recovery is by two 18 inch 'chutes that are silver mylar with tape dots for shroud line retention. Aye aye! I have modified this, as I have since 1969, when I be introduced t' t' hobby. An old timer who's name I can't recall showed me t' put t' tape dot on, put t' hole reinforcement rin' on t' back, me hearties, and usin' an Xacto drill a 1/8 inch hole in t' middle. T' finished rocket over all is impressive in size. Blimey! EASE OF BUILD: (Ratin' 5)

Finishing
There are no special requirements or techniques for finishing. Aye aye! I followed t' paint scheme on t' supplied card. T' one decal is o' t' peel and stick. Well, blow me down! Usin' t' soapy water technique it went on easily. T' one thin' is I needed t' do is t' cut it around t' launch lug. Well, blow me down! T' finished kit got many "Who makes that kit, me bucko, shiver me timbers, and where did you find it?" and "It looks classier than t' Mean Machine!" at t' first launch I brought it to. Aye aye! Well, blow me down! FINISHING: (Ratin' 5)

Construction Rating: 4 ½ out o' 5

LaunchFlight/Recovery
T' recommended motors for this are D12-5 & E15-7. Well, blow me down! I have flown this four times on t' D12-5. T' one gripe I have with Custom be t' motor hooks. Avast! They are thinner than t' Estes counterparts and I have only recovered t' Equinox with t' motor one time. Ya scallywag! With t' baffles preparation is: put t' 'chutes in and away t' t' RSO.

T' first flight was on a cold gray day in December. I be impressed by t' slow lift-off climbin' straight up with no wobble or wind cocking. Ahoy! Begad! T' delay was just right both 'chute blossomed and it softly landed about 500 feet from t' pads after reachin' an estimated altitude o' 600 feet. Well, blow me down! Well, blow me down! (wRASP) Upon recovery I found t' motor had kicked out. On t' second flight t' same result and durin' recovery only one 'chute fully opened. Begad! I guess it sat on t' pad too long for t' 33-degree temperature. Ahoy! No damage upon landing, matey, ya bilge rat, t' motor kicked out again, only this time t' motor hook was slightly burnt.

T' next flights came in February. Ya scallywag! Aye aye! It is a typical winter in Denver, shiver me timbers, Colorado, arrr, about 55 and a slight breeze. Blimey! Arrr! T' flights were great, with t' slow rise and gentle turn at apogee. Blimey! T' 'chutes opened and they brought t' rocket down gently. Begad! On t' first flight I taped t' motor in, ya bilge rat, but it kicked. Well, blow me down! Blimey! On t' second flight I also wire tied t' motor with t' tape and it held. Arrr! Arrr! I like t' way t' multiple 'chutes look, but for ease o' preparation, a single 18 inch or 24 inch would work. Arrr! I can't wait t' send this up on an E15-7, shiver me timbers, with an estimated altitude o' 1775 feet. (wRASP).

Flight Rating: 4 ½ out o' 5

Summary
Everythin' considered if it were nay for t' motor kickin' t' ratin' would be a 5. Begad! Avast, me proud beauty! I just love t' way this kit looks and flies. T' kit retails for $ 19.95 and I believe it is work every penny. Ahoy! T' biggest obstacle with t' kit as far as its durability is gettin' out t' door and t' t' launch sites. I really like t' Custom kits as they have t' flavor o' t' kits available in t' early '70s.

Overall Rating: 4 ½ out o' 5

Flights

Comments:

avatar
J.D. (June 1, 2000)
I surprised everyone at the field with my Equinox when it flew. A bit of a wobble that others said meant I needed a bit of noe weight. Can't wait to try it on an E.
avatar
K.J. (June 1, 2000)
My experience with the Equinox is very similar. It is a great honking huge rocket that goes together very quickly. It's size makes for impressively slow launches and is a real crowd pleaser. I've heard it has been discontinued, so if you can find one, buy it and build it.. you won't be disappointed.
avatar
J.D. (March 1, 2001)
Flew it on an E-18. Very nice flight. Still very happy with this rocket. Only thing I would have changed is to make it a center-break. This would make it easier to transport! Very light, and very straight flights with the extra power. Considering a second!
avatar
D.C. (August 25, 2009)
The Equinox is back in production now. I got one and we will probably use them for our annual October Skies Boy Scout Troop launch. I built mine mid-September. One issue I would take with the design is the current motor mount. It uses 4 heavy card centering rings, which "sandwich" two undersized spiral-wound centering rings (24mm to possibly BT-55 or BT-60--I don't have the instructions anymore), which don't make contact with the airframe. I would think it would be stronger to just use bigger spiral CRs because more surface area would be in contact with the airframe. But it is a really nice kit and I can't wait to fill the sky with them.
